Zircon ramming mass

Zircon ramming mass is a type of monolithic refractory with low plasticity. It has good integrity, sealing, strong adaptability, good corrosion resistance and high refrarotiness. It is widely used in the bottom of glass furnaces.It is composed of Zircon aggregate, powder material, binder and additives, which are mixed according to a certain proportion and then molded by ramming

Model Number:AZSR-50V,AZSM-06J,AZSM-05,AZSM-04L

Certification:ISO9001- 14001

Minimum Order Quantity:5 MT

Share With:

Zircin ramming mass description

It is composed of Zircon aggregate, powder material, binder and additives, which are mixed according to a certain proportion and then molded by ramming. Zircon aggregate is the skeleton of zircon ramming mass. Zircon ramming mass is widely used in the sealing and insulation of the glass furnace bottom. Although ramming mass accounts for a small proportion of the entire refractory materials, it is used in critical parts. It is subjected to severe environment, high temperature, corrosion by glass liquid and static penetration of glass liquid. Moreover, it is difficult to be repaired.

Zircon ramming mass characters:

1. High refractoriness, High refractoriness under load.
2. High density, low porosity.
3. Good slag resistance and corrosion resistance.
4. High strength and wear resistance.
5. Good resistance to flake performance.
6. Good thermal shock stability.
7. Scouring resistance
8. Good hot strength.

Zircon ramming mass physical and chemical:

Item		Behaviors
Item		AZSR-50V ERSOL 50	AZSM-06J ERSOL 06	AZSM-05 ERSOL 05	AZSM-04L ERSOL 04
Chemical Composition	Al2O3	48	48	48	48
	ZrO2	30	30	30	30
	SiO2	20	20	20	20
	Others	2	2	2	2
Bulk density g/cm3		3.2	3.1	3.1	3.1
Crystallographic analysis after being sintered at 1300/1500°C		Corundum, zirconium oxide	Corundum, zirconium oxide	Corundum, zirconium oxide	Corundum, zirconium oxide
Thermal conductivity		Good	Good	Good	Good
Anti-corrosion property		Excellent at 1300°C	Excellent at 1300°C	Excellent at 1300°C	Excellent at 1300°C
particle diameter of grain		0-5mm	0-0.6mm	0-0.5mm	0-0.4mm
Application temperature		Cold/low temperature	Cold/low temperature	Cold/low temperature	Cold/low temperature
Quantity of water		8-10% (proportion by weight)	10-12% (proportion by weight)	10-12% (proportion by weight)	10-12% (proportion by weight)
Solidification		Water (ceramic)	Water (ceramic)	Water (ceramic)	Water (ceramic)
Packaging		25kg/bag	25kg/bag	25kg/bag	25kg/bag
Quality guarantee period		12 months	12 months	12 months	12 months
Used for		Under bottom paving, spreading, Melting end and working area	Under bottom paving, spreading and the place between fused cast brick and ERSOL 50	Under bottom paving, spreading, and the joint between bricks of two layers that are between the fused cast brick and ERSOL 50	Joint between bricks of two
